grip into the edge of the tool. The up-
take spindle (27) must turn simultan-
eously when you turn the attachment
flange.
6. Place the keyless chuck (25) on the
uptake spindle (27). The flat side of
the keyless chuck faces the attachment
tool.
7. Press and hold the spindle lock (8).
8. Turn the uptake spindle (27) until the
stop button holds the uptake spindle
in a fixed position. Keep pressing the
spindle lock (8).
9. Tighten the keyless chuck (25).
You can release the spindle lock (8).
If you have fitted a cutting disc: Fit
the attachment onto the guard cover
(p.45).
Fitting and removing the wire
brush
CAUTION! Risk of injury
when touching the attachment
tool. Wear protective gloves
when handling the attachment
tool.
Tools required
• Open-end spanner (not included)
Removing the wire brushes
(Fig.D)
1. Press and hold the spindle lock (8).
2. Turn the uptake spindle (27) until the
stop button holds the uptake spindle
in a fixed position. Keep pressing the
spindle lock (8).
3. Release the wire brush with an open-
end spanner.
You can release the spindle lock (8).
Fitting the wire brush (Fig.D)
1. Place the desired wire brush onto the
uptake spindle (27).
2. Press and hold the spindle lock (8).
3. Turn the wire brush onto the uptake
spindle (27). Tighten the wire brush us-
ing a combination wrench.
You can release the spindle lock (8).
Fitting and removing the
attachment on the guard
cover
CAUTION! Risk of injury
when touching the attachment
tool. Wear protective gloves
when handling the attachment
tool.
Requirements
• Cutting disc mounted
• Battery removed from device
Fitting the attachment (17) (Fig.B)
1. Place the attachment (17) on the
guard cover (7) and turn the attach-
ment (17) until it audibly clicks into
place.
Removing the attachment (17)
(Fig.B)
1. Release one of the two locks (18) on
the attachment (17) by pushing the
lock (18) outwards.
2. Slide the released lock (18) over the
guard cover (7) until the attachment is
removed after half a turn.
Checking the battery charge
level
LEDs Meaning
red, orange, green Battery charged
red, orange Battery partially
charged
red Battery needs to be
charged
