Parrot DS3120 User Manual

10
Using the Audio Streaming function
Before using the Audio Streaming function, you must first connect your audio player to the
Parrot DS3120. If you are using this device with the Parrot DS3120 for the 1st time, you will
have to pair both devices.
► Refer to the «Connecting a Bluetooth device with the Parrot DS3120 » section for further
information.
Using an audio
player with the
Parrot DS3120 via
USB connection
The Parrot DS3120 enables you to play music files stored on
standard types of MP3 players but also on mass storage peripherals
(USB flash drive, external hard disk).
Make sure the external hard disk used with the Parrot
DS3120 consumes less than 500 mA.
1. Connect the audio player to the Parrot DS3120.
> The peripheral content is automatically displayed.
> To reach the peripheral content from the main menu, select
USB/SD and your audio player.
2. To visualize your audio player / USB flash drive content:
• If the tags of your music files are correctly defined,
select one of the following options: Playlist, Artist,
Album, Songs, and Genres.
• If the tags of your music files are not defined, select
Browse by directory, then:
- Use the arrows to browse the content of
your audio player.
- Press to enter a music folder or to start playing
a music file.
- Press to reach the previous folder (or select
« Root »).

Parrot DS3120 Specifications

Power

power supply input	100-220 V~, 50-60 Hz
power supply output	12Vdc, 2A

Bluetooth

bluetooth version	2.0 + EDR
bluetooth pin code	0000
supported bluetooth profiles	A2DP, AVRCP, FTP, OPP, SPP

Weight and Dimensions

dimensions	150 x 300 x 100 mm
weight	1.5 kg
