Parrot DS3120 User Manual

4
Using the Parrot DS3120 for the first time
Setting up the
Parrot DS3120
1. Connect the mains cable to the Parrot DS3120 or insert the
batteries observing the + and - polarity signs indicated in the
batteries compartment.
2. Get the antenna out of the batteries compartment to improve
the reception quality.
► Refer to the « Unrolling the antenna » section for further
information.
3.
Hold down the button until the screen
lights on.
Use the same button to turn off the Parrot
DS3120.
If the Parrot DS3120 is in idle mode, press any button to display the
main menu.

Parrot DS3120 Specifications

Power

power supply input	100-220 V~, 50-60 Hz
power supply output	12Vdc, 2A

Bluetooth

bluetooth version	2.0 + EDR
bluetooth pin code	0000
supported bluetooth profiles	A2DP, AVRCP, FTP, OPP, SPP

Weight and Dimensions

dimensions	150 x 300 x 100 mm
weight	1.5 kg
