1. Main components and General information
1.1 Main components
22
11
6
19
20
21
18
17
14
15
16
13
12
10
9
8
7
5
4
3
2
1
1. Top cowling 9. Clamp bracket 17. Throttle grip
2. Top cowling lock handle 10. Steering friction bolt 18. Clamp bolt
3. Drain screw 11. Tiller handle 19. Rope attachment
4. Anti-cavitation plate 12. Starters handle 20. Tilt lock lever
5. Trim tab 13. Warning indicator 21. Fuel joint
6. Propeller 14. Gear shift lever 22. Fuel tank
7. Cooling water inlet 15.
Engine stop button/Engine stop lanyard switch
8. Trim rod 16. Throttle frication adjuster
1
