Avoid accidentally pulling the lanyard during normal operation. Loss of engine power means the
loss of steering control. Also, without engine power, the boat could slow rapidly. This could
cause people and objects in the boat to be thrown forwar
d.
NOTE:
The start-in-gear protection device prevents the engine
from starting except when in neutral. Attach the engine
stop switch lanyard to secure place on your clothing, or
your arm or leg. Then install the lock plate on the other
end of the lanyard into the engine stop switch.
4. Place the throttle grip in the “START”(start)position. Turn the main switch to “ON”(on).
5. Press in and hold the main switch to operate
the remote choke system. Turn the main switch
to “START”(start), and hold it for a maximum or
5 seconds.
18
ON
START
