ASLD2200 - Instruction Manual
6 Configuration
The ASLD2200 requires very little configuration, the user must check the following details before use. If you find that
the incorrect sensor or encoder disc has been purchased contact Partech to arrange a replacement.
6.1 Sensor Selection
The IR sensors are available in four ranges; which are shown below along with typical applications.
Part
Description Typical Application
102201 IR100, Range 0-200 mg/l Water Treatment Clarifiers
101901 IR40, Range 0-1,500 mg/l Sewage Treatment Final Settlement Water Treatment Primary
101601 IR15, Range 0-10,000 mg/l Sewage Treatment Primary Water Treatment Thickeners
148121 IR8, Range 0-30,000 mg/l Sewage Treatment Thickeners
6.2 Depth Range Selection
The depth range depends on the encoder disc that has been fitted to the instrument, this can be found near the motor
assembly.
Motor Assembly Version 2
CURRENT VERSION
(Thick aluminium side plates)
Motor Assembly Version 1
OLD VERSION
(Thin stainless steel side plates)
No of Blades Minimum Range
(metres)
Maximum Range
(metres)
Minimum Range
(metres)
Maximum Range
(metres)
1 11.0 20.0 5.6 13.8
2 5.5 11.0 2.8 6.9
4 3.0 6.0 1.4 3.4
6 2.0 4.0 1.0 2.2
8 1.5 2.5 0.8 1.6
The instrument will have been fitted with one of these encoder discs, and will have been selected prior to order
placement. The encoder disc can be changed in the field if required, see the rear of the manual for part numbers.
Page 14 of 30 103370IM Issue 10 Date 19/03/2018
