ASLD2200 - Instruction Manual
3.2 Encoder Disc Selection
The ASLD2200 is supplied with a selection of encoder discs. The disk choice is dependant on the depth of the
measurement tank.
3.2.1 Encoder Disc Ranges
Number of Blades Tank Depth (m)
1 11-20
2 5.5-11
4 3-6
6 2-4
8 1.5-2.5
103370IM Issue 10 Date 19/03/2018 Page 9 of 30
