ASLD2200 - Instruction Manual
11 Fault Finding
Listed below are some of the common problems found on the ASLD2200, the list is not comprehensive and if you are
in any doubt please contact your local distributor or Partech.
11.1 Symptom: Digital display changes but does not relate correctly to the sensor position
Fault: Encoder incorrectly positioned
Remove motor assembly cover as per photograph below
Page 22 of 30 103370IM Issue 10 Date 19/03/2018
