55
Power Button
Before proceeding, remove
the following FRUs.
• Panel
• Panel Back Cover
1. Disconnect the cable
from the mainboard and
the power button PCBA.
2. Remove 2 screws that
secure the power button
PCBA.
3. Remove the power
button.
