59
LED Cable
Before proceeding, remove
the following FRUs.
• Panel
• Panel Back Cover
1. Disconnect the LED
cable.
I/O Shield
Before proceeding, remove
the following FRUs.
• VGA Port
1. Remove the 3 screws
that secure the I/O
Shiled on Panel Bracket.
2. Remove the I/O Shiled.
