Partner A4-1-K - VGA Port

57
VGA Port
Before proceeding, remove the
following FRUs.
• Panel
• Panel Back Cover
1. Disconnect the VGA port
connector.
2. Remove the screw that
secures the VGA port
grounding wire on the
motherboard.
3. Remove the 2 hex screws
on either side of the VGA
port.
4. Remove the VGA port.
