18
10.3 Gas Equipment
Everyday Gas Regulators – 300 BAR
Single Stage
Features
Flow rate up to 96m
3
/h (3389 ft
3
/h).
• Full 300 bar capability.
• Outlet pressure indicated on the bonnet.
• Bottom entry design suited for top outlet
cylinder valves.
Fittings
• Fitted with standard 3/8" BSP outlet.
• Fitted with 5/8" BSP inlet connections.
Stock Code Description Maximum Outlet Pressure
E700140 Argon Preset Regulator 3.0 Bar
E700141 Argon Indicator Regulator 3.0 Bar
E700113 1 Gauge Argon 30 lpm ow
E700123 2 Gauge Argon 30 lpm ow
Flow Meters
Features
• Designed from brass bar whilst the tube
and cover are moulded from high quality
polycarbonate to ensure high impact
resistance and clarity.
• Calibrated to operate at an inlet pressure
of 30PSI.
• Sensitive needle valve provides easy
adjustment and the downward facing
outlet connection eliminates hose kinking.
Fittings
• Fitted with standard
3
/8" BSP inlet and outlet connections.
Stock Code Description
706101 Flow Meter Mixed Gas 25 lpm (MIG)
706100 Flow Meter 0-12 lpm (TIG)
10.0 Accessories
10.1 Feed Rolls
10.2 Torch Spares
Available on page 17 of this manual, and from the machine
HELP menu.
Gas ow Tester
• Designed to check gas ow at the front of MIG Torches.
Stock Code Description
806001 Gas ow Tester
Part No. Groove Wire Sizes Wires
DR2V0608 Plain V 0.6 - 0.8 Fe, Ss
DR2V0809 Plain V 0.8 - 0.9 Fe, Ss
DR2V0810 Plain V 0.8 - 1.0 Fe, Ss
DR2K0608 Knurled V 0.6 - 0.8 FC
DR2K0809 Knurled V 0.8 - 0.9 FC
DR2K0810 Knurled V 0.8 - 1.0 FC
DR2U0809 Plain U 0.8 - 0.9 Al
DR2U0810 Plain U 0.8 - 1.0 Al
