Parweld XTM 201Di - Default Chapter; Table of Contents

3
www.parweld.com
Contents
Page
1.0 Safety Precautions 4-5
2.0 Product Description 5
3.0 Technical Specications 6
4.0 Installation 6
4.1 Location 6
4.2 Input and Grounding Connection 6
5.0 Description of controls 7
6.0 Operation 8-10
6.1 Use of Controls 8
6.2 Language of Operation 8
6.3 Process Selection 8
6.4 MIG Welding Preparing the Machine 9-10
7.0 Setting the Machine for MIG Welding 10-13
7.1 MIG SYN - Synergic MIG Welding 10
7.2 MIG MAN - Manual MIG Welding 11
7.3 Remote Control MIG Torch 11
7.4 MMA Welding 11-12
7.5 TIG Welding 12-13
7.6 TIG Welding Operation Guide 13
8.0 Fault Finding 13-16
8.1 MIG Welding Problems 13-14
8.2 MMA Welding Problems 15
8.3 TIG Welding Problems 16
9.0 Control Torch Schematic 17
10.0 Accessories 18
10.1 Feed Rolls 18
10.2 Torch Spares 18
10.3 Gas Equipment 18
11.0 EC Declaration of Conformity 19
11.1 RoHS Compliance Declaration 19
11.2 WEEE Statement 20
11.3 Statement of Warranty 20
