TOOL AND FASTENER SPECIFICATIONS
TOOL SPECIFICATIONS
MODEL NO. LL350S
HEIGHT 14.5”
WIDTH
4.25
”
WIDTH
4.25
LENGTH 18.5”
WEIGHT 8.5 lbs
OPERATING PRESSURE 80 to 110 p.s.i. (5.5 to 8.0 bars)
FASTENER SPECIFICATIONS
NAIL TYPE
30-35⁰papercollatedstripframing
nails
NAIL LENGTH 2” to 3 1/2”
NAIL HEAD DIAMETER .113 to .131
TOOL AIR FITTINGS:
This tool uses a 3/8” N.P.T. male plug. The fitting must be capable of discharging tool air
pressure when disconnected from the air supply
OPERATING AIR PRESSURE:
80 to 110 p.s.i. (5.5 to 8.0 bars). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
