Revision 25 of DOCU225, © Copyright
click the Decimals drop-down box in the highlighted row and select 0, 1, 2, or
3 decimal places.
• Shelf Life
To select the length of time the EDR displays the WITS data, click the Shelf
Life drop-down list and choose 5 Mins (minutes), 15 Mins, 1 Hour, 12
Hours, 1 Day, or Never Expires. Once the shelf life period is exceeded, the
EDR changes the value of the trace to null, represented by two dashes (– –).
Important:
Shelf life is an important selection for time sensitive data. The EDR displays the last
received WITS value until the sender transmits a new value, or until it reaches the
end of the shelf life period. WITS data with a long shelf life can be misleading if users
don’t know the data’s age.
5. To enable your custom code to be sent or received, click on the code’s Enable
check box.
6. Click Save > Exit to return to the Setup Menu.
When you are finished, click Save > Exit. The EDR can now receive the custom WITS
code. To send this code, follow the directions in Selecting Custom WITS Codes to Send
below.
You can return all custom WITS settings to default at any time by clicking the Factory
Reset button.
