4.11 Default Pason WITS Codes
The following table lists the default Pason WITS names and codes, whether the EDR
can receive the code, and which codes are sent in the different EDR WITS modes. In
addition, the EDR can be configured to receive up to 50 additional custom WITS codes.
Note:
All data values sent via WITS are in float format (e.g. “####.##”).
Note:
When sending gamma and gamma depth values to the EDR via WITS, both values need to be in
the same WITS packet.
Name
WITS
Code
EDR can
Receive
EDR Sends in
Full WITS
Mode
EDR Sends in
Half WITS
Mode
Record 01: General Time Based
Available Transmission Types: Time Based or Request-Response
Well ID
0101
Date
0105
Time 0106
Bit Depth
0108
Y
Y
Y
Hole Depth
0110
Y
Y
Y
True Vertical Depth 0111 Y
Block Height 0112 Y Y
On Bottom ROP
0113
Y
Y
Y
Hook Load (maximum) 0115 Y Y
Weight on Bit
0117
Y
Y
Rotary Torque
0119
Y
Y
Rotary Rpm 0120 Y Y
Standpipe Pressure
0121
Y
Y
Casing Pressure
0122
Y
Y
Pump 1 strokes/min 0123 Y Y Y
Pump 2 strokes/min 0124 Y Y Y
Pump 3 strokes/min
0125
Y
Y
Y
Total Mud Volume 0126 Y
PVT Total Mud Gain/Loss
0127
Y
Flow
0128
Y
Pump Rate 0130 Y Y
Total Strokes P1+P2+P3+P4
0137
Y
Y
3
rd
Party LagD
0139
Y
Y
