Inline PSU Tester – User’s Guide Page 27
some PCI sound-cards. These are starting to become very rare, therefore this
failure alone is not enough to render this PSU as faulty or not usable.
Figure 23
- Efficiency: Using BurnInTest, we put system under load by running a
combination of tests simultaneously.
Test load 1: CPU (General purpose instructions, 1 Threads)
Test load 2: CPU (General purpose instructions, 2 Threads) and 3D Graphics test
(window size 320x200 pixels)
Test load 3: CPU (Max heat, 16 Threads) and 3D Graphics test (window size
640x480 pixels)
Table 19
The PSU does not meet the 80 Plus Gold efficiency requirements. Expected
efficiency at gold level at 20% and 50% load are 88% and 92% respectively.
