PERFORMANCE DATA
NOMINAL CAPACITIES
OUTDOOR UNIT
PH1S
INDOOR UNIT
PF1B
AIRFLOW
(Cfm)
GROSS COOLING
CAPACITY (Btuh)
NET HEATING
CAPACITY (Btuh)
090 090 3000 89,000 83,000
NOTES:
1. Gross cooling capacity is based on 67 F wb, 80 F db air entering in-
door unit and 95 F db air entering outdoor unit.
2. Net heating capacity is based on 70 F db air entering indoor unit and
47 F db, 43 F wb air entering outdoor unit. Includes indoor fan heat
and defrost effects.
INTEGRATED HEATING CAPACITIES
OUTDOOR
UNIT
PH1S
INDOOR
UNIT
PF1B
AIRFLOW
(Cfm)
TEMPERATURE OF AIR ENTERING OUTDOOR UNIT (F db)
-1001017203040475060
Cap. kW Cap. kW Cap. kW Cap. kW Cap. kW Cap. kW Cap. kW Cap. kW Cap. kW Cap. kW
090 090 3000 21.7 3.4 30.4 3.8 39.4 4.3 45.8 4.6 48.3 4.8 56.2 5.3 75.9 5.9 83.4 6.3 86.8 6.5 98.4 7.1
LEGEND
Cap. — Integrated Heating Capacity (1000 Btuh) — includes indoor-
fan motor heat and effects of defrost.
kW — Total Compressor Motor Power Input
NOTES:
1. To obtain total outdoor unit power, add outdoor fan kW shown to
compressor draw: PH1S090 — .96 kW.
2. Ratings are without supplementary heat and are based on 70 F db
air entering indoor unit. Wet-bulb temperature entering outdoor unit
varies with dry bulb; at 47 F db, wb is 43 F; at 17 F db, wb is 15 F.
COMBINATION RATINGS
GROSS CAPACITIES — COOLING
PH1S090 WITH PF1B090
Temp (F)
Air Ent
Outdoor
Unit
Airflow Air Entering Indoor Unit — Cfm/BF
2250/0.09 3000/0.12 3750/0.14
Temp Air Entering Indoor Unit — Ewb (F)
72 67 62 72 67 62 72 67 62
85
TC 96.9 89.1 81.9 101.0 93.3 86.7 104.0 95.9 90.9
SHC 48.7 60.5 72.2 53.8 69.0 82.9 58.5 76.6 90.2
kW 6.44 6.24 6.06 6.54 6.34 6.18 6.60 6.41 6.27
95
TC 92.6 85.1 78.2 96.4 89.0 82.8 98.8 91.5 86.8
SHC 47.1 58.9 70.3 52.2 67.4 80.6 56.8 75.0 86.8
kW 7.03 6.80 6.58 7.14 6.93 6.73 7.21 7.00 6.86
100
TC 90.3 83.1 76.3 94.0 86.8 80.9 96.3 89.2 84.9
SHC 46.2 58.0 69.4 51.3 66.5 79.4 55.9 74.0 84.9
kW 7.32 7.07 6.84 7.44 7.21 7.00 7.51 7.29 7.14
105
TC 88.0 81.0 74.3 91.6 84.5 78.8 93.7 86.8 82.8
SHC 45.3 57.2 68.4 50.5 65.6 78.0 55.1 73.1 82.8
kW 7.60 7.34 7.08 7.74 7.48 7.26 7.81 7.57 7.41
115
TC 83.3 76.5 70.4 86.4 79.7 74.9 88.4 81.9 79.0
SHC 43.6 55.4 66.4 48.7 63.7 74.9 53.3 71.1 79.0
kW 8.17 7.86 7.58 8.30 8.01 7.79 8.39 8.11 7.98
125
TC 78.3 71.8 66.3 81.1 74.7 71.0 83.0 76.8 74.7
SHC 41.8 53.5 64.1 46.9 61.8 71.0 51.5 68.9 74.7
kW 8.71 8.36 8.05 8.86 8.52 8.32 8.95 8.63 8.51
LEGEND
BF — Bypass Factor
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW — Compressor Motor Power Input, Total
Ldb — Leaving Dry Bulb
Lwb — Leaving Wet Bulb
SHC — Sensible Heat Capacity, Gross (1000 Btuh)
TC — Total Capacity, Gross (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. SHC is based on 80 F db air entering indoor coil.
Below 80 F db, subtract (Corr Factor x Cfm) from SHC.
Above 80 F db, add (Corr Factor x Cfm) to SHC.
BYPASS
FACTOR
ENTERING-AIR DRY-BULB TEMP (F)
79 78 77 76 75 under 75
81 82 83 84 85 over 85
Correction Factor
0.03 1.07 2.13 3.20 4.27 5.34
Use formula
given.
0.06 1.03 2.07 3.10 4.14 5.17
0.09 1.00 2.00 3.00 4.00 5.01
0.12 0.97 1.94 2.90 3.87 4.84
0.15 0.94 1.87 2.81 3.74 4.68
Interpolation is permissible.
Correction Factor = 1.10 x (1 – BF) x (db – 80)
3. Formulas:
sensible heat capacity (Btuh)
t=t–
ldb edb
1.10 x cfm
t = wet-bulb temperature corresponding to enthalpy of air
lwb
leaving indoor coil (h )
lwb
total capacity (Btuh)
h=h –
lwb ewb
4.5 x cfm
where h = enthalpy of air entering indoor coil
ewb
4. Capacities are based on 25 actual ft (40 equivalent ft) of intercon-
necting piping sized to the outdoor unit field connections. (Equivalent
length is equal to the actual length plus a 50% allowance for fitting
losses.)
