Payne PH1S - Electric Heater Data - Indoor Unit; Fan Motor Specifications; Electric Heater Specifications

ELECTRICAL DATA (cont)
ELECTRIC HEATER DATA — INDOOR UNIT
HEATER
PART NO.
V-Ph-Hz
FAN
MOTOR
ELECTRIC HEATER(S)
MCA* MOCP*
Nom.
Cap.
(kW)
Actual Capacity (kW)
FLA
Hp FLA Stage 1 Stage 2 Total
CAELHEAT001A00
208-3-60
2.4† 11.0 5 3.8 — 3.8 10.4 26.8 35
2.4 5.8 5 3.8 — 3.8 10.4 20.3 25
240-3-60
2.4† 11.0 5 5.0 — 5.0 12.0 26.8 35
2.4 5.8 5 5.0 — 5.0 12.0 22.3 25
CAELHEAT004A00
208-3-60
2.4† 11.0 10 7.5 — 7.5 20.8 39.8 45
2.4 5.8 10 7.5 — 7.5 20.8 33.3 35
240-3-60
2.4† 11.0 10 10.0 — 10.0 24.1 43.8 45
2.4 5.8 10 10.0 — 10.0 24.1 37.3 40
CAELHEAT005A00 480-3-60 2.4 2.6 10 10.0 — 10.0 12.0 18.3 20
CAELHEAT007A00
208-3-60
2.4† 11.0 15 11.3 — 11.3 31.3 52.8 60
2.4 5.8 15 11.3 — 11.3 31.3 46.3 50
240-3-60
2.4† 11.0 15 15.0 — 15.0 36.1 58.9 60
2.4 5.8 15 15.0 — 15.0 36.1 52.4 60
CAELHEAT008A00 480-3-60 2.4 2.6 15 15.0 — 15.0 18.0 25.8 30
CAELHEAT010A00
208-3-60
2.4 5.8 25 11.3 7.5 18.8 52.1 72.4 80
2.4† 11.0 25 11.3 7.5 18.8 52.1 78.9 80
240-3-60
2.4 5.8 25 15.0 10.0 25.0 60.1 82.4 90
2.4† 11.0 25 15.0 10.0 25.0 60.1 88.9 90
CAELHEAT011A00 480-3-60 2.4 2.6 25 15.0 10.0 25.0 30.1 40.8 45
CAELHEAT013A00
208-3-60
2.4 5.8 35 15.0 11.3 26.3 73.0 98.5 100
2.4† 11.0 35 15.0 11.3 26.3 73.0 105.0 110
240-3-60
2.4 5.8 35 20.0 15.0 35.0 84.2 112.5 125
2.4† 11.0 35 20.0 15.0 35.0 84.2 119.0 125
CAELHEAT014A00 480-3-60 2.4 2.6 35 20.0 15.0 35.0 42.1 55.9 60
LEGEND
ETL — Engineering Testing Laboratory
FLA — Full Load Amps
Hp — Horsepower
MCA — Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection (Amps)
Nom. Cap. — Nominal Capacity
*Values shown are for single-point connection of electric heat accessory
and air handler.
†Single-phase motors. All other motors are 3-phase.
NOTES:
1. Electrical resistance heaters are rated at 208 v, 240 v, and 480 v. To
determine heater capacity (kW) at unit nameplate voltage, multiply
the 208-v, 240-v, or 480-v capacity (kW) by the factor shown in the
table at right for the unit voltage.
FAN CONTACTOR COIL — INDOOR UNIT
UNIT PF1B VOLTAGE (vac) MAX HOLDING VA
090 24 10
HEATER
RATING
VOLTAGE
ACTUAL HEATER VOLTAGE
200 208 230 240 400 440 460 480
208 .924 1 1.222 1.331 — — — —
240 .694 .751 .918 1 — — — —
480 — — — — .694 .840 .918 1
2. The following equation converts kW of heat energy to Btuh:
kW x 3,412 = Btuh.
3. Heater contactor coils are 24 v and require 8 va holding current.
4. Electric heaters are tested and ETL approved at maximum total
external static pressure of 1.9 in. wg.
16
