NMS044 Reference Manual Connecting the Gateway to Cellular Service 16
LEARN MORE
For additional information, see “Gateway LED Indications” on
page A-3.
Step 3. Open a web browser on the connected PC, and enter “http://
192.168.14.31:9191” into the address bar. This opens ACEmanager, the
gateway configuration console.
Step 4. If this is your first time logging in, log in as “user” with the password
“LD_NMSystem16.”
Figure 2-8 User Login
TAKE NOTE If the login is not working, it’s possible that the gateway has not
been configured for use with Larson Davis instruments. If this is the case, refer
to section “
Configuring the Gateway for Larson Davis Instruments” on
page A-11.
Step 5. Change the password as shown in steps 5a–5e.
Changing Your Password
a. Navigate to the Admin menu, as shown in Figure 2-9.
b. If this is your first time logging in, enter “user” with the password
“LD_NMSystem16”. Otherwise, log in with the user name and password
previously set for this system.
TAKE NOTE If you need to reset the gateway to factory settings at some future
time. Examine the label on the bottom of the modem for the factory password.
Figure 2-9 Admin Tab
c.
On the Change Password sidetab, enter a unique password in New Password,
and again in Retype Password.
d. Record your password. If you forget it you will need to reset the gateway to
factory settings and reconfigure.
To Next Page
