NMS044 Reference Manual Configuring the Gateway for Larson Davis Instruments A-13
A.5.2 Configuring LD Settings Utilizing the Template File
Utilizing the LD settings template file is the fastest and simplest method of configuring the
gateway.
Step 1.
Log in to ACEmanager as shown in
A.5.1 Logging In to ACEmanager on page A-11
.
Step 2. Select Template in the top right. This opens the Template upload window.
Figure A-11
Step 3.
To upload the RV50X configuration template, do the following:
Download the “RV50XTemplateFile.xml” from the Larson Davis NMS044
Product Page. Then click Choose File, select the downloaded template file,
and click Upload.
Step 4. Select Apply. The gateway configuration is complete.
A.5.3 Configuring LD Settings Without the Template File
If you purchased your RV50X gateway from someone other than Larson Davis, or if your
gateway has been restored to factory default settings, you need to configure it for use with
Larson Davis instruments. You may manually configure the RV50X gateway for use with
Larson Davis instruments, as shown in this section.
Step 1. Log in to ACEmanager as shown in A.5.1 Logging In to ACEmanager.
