PCTEL SeeGull - CW Transmitter Interface

SeeGull CW Transmitter User Guide
Rev. D PCTEL 8
3.2 CW Transmitter Interface
Figure 2 - Interface
1. Antenna port interface.
2. LCD menu screen.
3. Keypad.
4. Charger socket.
5. USB: Strictly for PCTEL calibration and firmware updates. Not intended for customer use.
1
2
3
4
5
