PDG Mobility Stellar Series - Frame Options (and Identification)

PAGE 19
Class 1 Medical
Rev. 2
14.2 Frame Options (and Identification)
Standard Base
and Seat
Frame
 250 lbs Weight Capacity.
Light Weight (LT)
Configuration available.
 Not recommended for
agitated users.
 Can be identified by
rectangular shaped
crossbar at the rear of the
lower frame.
Figure 14.1
Upgraded Base
and Seat
Frame
 300 lbs Weight Capacity
with addition of a
secondary Gas Strut.
 Available for Seat Widths
up to 22”.
Figure 14.2
Heavy Duty
Base and Seat
Frame
 450 lbs Weight Capacity.
Available for all sizes, but
required for seat width of
23” or wider.
 Requires 20” Composite
or 24” Heavy Duty Spoke
Wheels.
 Fixed Axles only.
 Not compatible with
Transit Tie Down System.
Figure 14.3
