PDG Mobility Stellar Series - Page 43

PAGE 43
Class 1 Medical
Rev. 2
Table 15.3: Stellar GL wheelchair test configuration
Seat Width
460 mm
Seat Depth
450 mm
Backrest Height
460 mm
Wheelchair Weight
31.8 kg
Seat Sling
Metal base plate with removable padded seat cushion
Back Upholstery
Removable, contoured padded
Wheels
1.5” (40mm) width, 26” (600mm) pneumatic tires
Casters
1.77” (45mm) width, 8” (200mm) diameter pneumatic tires
Footrest
Swing away, removable, heel straps
Other options
Single bar type adjustable pivoting angle push handles.
Removable, height adjustable, padded armrest
Mass of ATD
114kg (250lbs)
Max. User Weight
114kg (250lbs)
Table 15.4: Stellar GL wheelchair performance values
Feature
Min
Max
Feature
Min
Max
Overall length with
legrest
940 mm
1165 mm
Seat plane angle
5°
25°
Overall width
675 mm
675 mm
Effective seat depth
530 mm
530 mm
Folded length
n/a
n/a
Effective seat width
405 mm
405 mm
Folded width
n/a
n/a
Seat surface height at
front edge
410 mm
n/a
Folded height
n/a
n/a
Backrest angle
9.9°
29.9°
Total mass
31.8 kg
31.8 kg
Backrest height
560 mm
560 mm
Mass of heaviest part
n/a
n/a
Footrest to seat
distance
n/a
n/a
Static stability downhill
n/a
n/a
Leg to seat surface
angle
n/a
n/a
Static stability uphill
n/a
n/a
Armrest to seat
distance
n/a
n/a
Static stability sideways
n/a
n/a
Front location of
armrest structure
n/a
n/a
Energy consumption
n/a
n/a
Hand rim diameter
n/a
n/a
Dynamic stability uphill
n/a
n/a
Horizontal location of
axle
n/a
n/a
Obstacle climbing
n/a
n/a
Minimum turning
radius
n/a
n/a
Minimum braking
distance from max
speed.
n/a
n/a
Maximum speed
forward
n/a
n/a
The Stellar and Stellar GL wheelchair confirms to the following standards:
