20
IPMIP Motherboard Reference Guide
7 Connectors
SYS_FAN1
Chassis Fan connector
Connect the fan cables to the fan connectors on the motherboard, making sure that
the black wire of each cable matches the ground pin of the connector.
Ground
CHA FAN PWM
CHA FAN IN
CHA FAN PWR
