Pego ECP200 BASE Series - TeleNET Network Connection Wiring Diagram

ECP200 BASE 2/4
Page 32
USE AND MAINTENANCE MANUAL
Rev. 01-09
TeleNET NETWORK CONNECTION WIRING DIAGRAM
BEFORE CONNECTING UP COMMUTATE THE DATAPRINTER PLUS
(PRINTER) / TeleNET FUNCTION VIA DIP-SWITCH AS INDICATED IN
CHAP. 6, PAGE 23.
Allegati / Appendice
s
A.10
(
Morsettiera di collegamento TeleNE
T
Terminal block TeleNET connection
