ECP200 BASE 2/4
Page 6
USE AND MAINTENANCE MANUAL
Rev. 01-09
IMPORTANT INFORMATION FOR THE INSTALLER
1. Install the device in places where the protection rating is observed and try not to
damage the box when drilling holes for wire/pipe seats.
2. Do not use multi-polar cables in which there are wires connected to inductive/power
loads or signalling wires (e.g. probes/sensors and digital inputs).
3. Do not fit power supply wiring and signal wiring (probes/sensors and digital inputs) in
the same raceways or ducts.
4. Minimise the length of connector wires so that wiring does not twist into a spiral shape
as this could have negative effects on the electronics.
5. Fit a general protection fuse upstream from the electronic controller.
6. All wiring must be of a cross-section suitable for relevant power levels.
7. When it is necessary to make a probe/sensor extension, the wires must have a cross-
section of at least 1 mm
2
.
STANDARD ASSEMBLY KIT
For the purposes of assembly and use, the electronic ECP200 BASE control unit comes
with:
• N° 3 seals, to be fitted between the fixing screws and the box back panel
• N° 1 user’s manual.
CHAPTER 2: INSTALLATION
CHAP. 2 - Installation
