Pego ECP200 BASE Series User Manual

ECP200 BASE 2/4
Page 33
USE AND MAINTENANCE MANUAL
Rev. 01-09
SCHINT230 OPTIONAL KIT
With the optional SCHINT230 KIT is possible a simple connection with outputs
powered for direct control of functions.
A
llegati / Appendices
A.11
Power supply
230Vac 50Hz
Outputs powered for
direct control of functions
.
Digital input and
probe connections
SCHINT230 optional kit
Connect the ECP BASE terminal block to the SCHINT230 terminal block with the wire kit .
The connections must be realized PIN to PIN respecting the wire numbers.
