ECP200 BASE 2/4
Page 5
USE AND MAINTENANCE MANUAL
Rev. 01-09
OVERALL DIMENSIONS
IDENTIFICATION DATA
The unit described in this manual has an ID plate on the side showing all the relevant
identification data:
• Name of Manufacturer
• Code and model of unit electrical board
• Serial number
• IP protection rating
• Power supply
1.3
1.4
CHAP. 1 - Introduction
