ECP200 BASE 2/4
Page 4
USE AND MAINTENANCE MANUAL
Rev. 01-09
GENERAL
The electronic controllers of the ECP200 BASE series have been designed to control
static or ventilated cold rooms.
The ECP200 BASE 4 electronic board allows the user to control all the components on a
refrigeration unit such as compressor, evaporator fans, defrosting elements and cold room
light.
The applications are:
- single-phase static or ventilated refrigeration systems up to 2 HP, with off-cycle or
electrical defrosting
- out of room unit to be connected to power board for compressor, defrosting and fan
start.
- single-phase evaporator control unit with cold solenoid consensus or remote
condensing unit consensus
The ECP200 BASE 2 electronic board allows the user to control the compressor and room
light.
The applications are:
- single-phase refrigeration systems up to 2 HP with off-cycle defrosting.
- out of room unit to be connected to power board for compressor start.
The ABS controller box is simple to install and can easily be wall-mounted as the ECP200
BASE is extremely compact and features an IP65 protection rating.
PRODUCT ID CODES
ECP200 BASE 2 controls and manages compressor and
room light.
ECP200 BASE 2 A controls and manages compressor and
room light. Alarms relay.
ECP200 BASE 4 controls and manages compressor,
defrosting elements, evaporator fans and
room light.
ECP200 BASE 4 A controls and manages compressor,
defrosting elements, evaporator fans and
room light. Alarms relay.
1.1
1.2
CHAPTER 1: INTRODUCTION
CHAP. 1 - Introduction
