PELLENC POWER TOOLS BATTERY 150
56_158889-A
4.4. FITTING THE HOLSTER TO THE BELT
1. Detach the hook and loop strap (1).
2. Pull the hook and loop strap (1) out of the belt loop
(2).
3. Install the holster (3) on the belt (4).
Note
When fitting the holster on the right, ensure
that the hook and loop strap is on your right.
When fitting the holster on the left, ensure that
the hook and loop strap is on your left.
4. Position the hook and loop strap (1) on the holster
(3).
5. Slide the end of the hook and loop strap (1) into the
belt loop (2).
6. Pull and fasten the hook and loop strap (1).
7. Position the belt at waist level and adjust the tight-
ness with the tabs (5).
8. Clip the battery (6) onto the belt (4) and connect the
tool power cord (7) to the tool, see Section 4.5, “Tool
connection”.
9. Put the tool in the holster (3).
10. Attach the tool power cord (7) to the arm using the
armband provided, see Section 4.6, “Putting the lead
and wrist strap in place ”.
4.5. TOOL CONNECTION
Note
For more information on connecting the tool to the battery, refer to the tool's operating instructions manual.
13
