Pelpro PPC90 - Vent Termination Clearances

PelPro Cast Pellet Stove • 7093-600 • 07/13/16 pelprostoves.com8
Installing Your Stove
Vent Termination Clearances
Installing Your Stove
A
D
B
L
C
K
J
B
I
H
G
F
Clearan ces
A 12 ” Clearance above grade, veranda porch, deck or balcony (Including vegetation and mulch)
B
12 ” w i th ou tsi d e ai r ki t
4 8 ” n o ou tsi d e ai r ki t
Clearan ce b esi d e or b elow an y w i n d ow s or d oors th at open
12 ” * Clearan ce ab ove an y w i n d ow or d oor th at open s
C 18 ”
Vertical clearance to ventilated soft located above the terminal within a horizontal distance of 2 feet from
th e cen ter li n e of th e termi n al
D 12 ” Clearan ce to an ou tsi d e corn er w all
F
12 ” w i th ou tsi d e ai r ki t
4 8 ” n o ou tsi d e ai r ki t
Clearan ce to a n on -mech an i cal ai r su pply i n let to th e b u i ld i n g or a comb u sti on ai r i n let to an y oth er
appli an ce
G 36” Clearan ce to a mech an i cal ai r su pply i n let
H 8 4 ” * * Clearan ce ab ove a paved si d ew alk or paved d ri vew ay located on pu b li c property
I 12 ” * * Clearan ce u n d er a veran d a, porch , d eck or b alcon y
J 12 ” Clearan ce ab ove th e roof
K 2 4 ” Clearan ce f rom an ad j acen t w all i n clu d i n g n ei g h b ori n g b u i ld i n g s
L
36” w i th i n a h ei g h t of 15
f eet ab ove th e meter /
reg u lator assemb ly
Clearan ce to each si d e of cen ter li n e ext en d ed ab ove n atu ral g as or propan e meter / reg u lator assemb ly
or mech an i cal ven t
Notice:
Do NOT terminate vent:
• In any location that will allow ue gases or soot from
en teri n g or stai n i n g th e b u i ld i n g
• I n an y locati on w h i ch cou ld create a n u i san ce or h aza rd
• I n an y en closed or semi -en closed area su ch as a
carport, g arag e, atti c, craw l space, u n d er a su n d eck or
porch or n arrow w alkw ay
• Closely f en ced area, or an y locati on th at can b u i ld u p
a con cen trati on of f u mes su ch as a stai rw ell, covered
b reeze w ay , etc.
Notice:
Do NOT terminate below an air inlet.
• It is recommended that at least 60” (1.52m) of vertical
pi pe b e i n stalled w h en appli an ce i s ven ted d i rectly
th rou g h a w all—t h i s w i ll create a n atu ral d raf t, w h i ch
w i ll h elp preven t th e possi b i li ty of smoke or od or
ven ti n g i n to th e h ome d u ri n g a pow er ou tag e
• I t w i ll also ke ep exh au st f rom cau si n g a n u i san ce
or h aza rd b y exp osi n g people or sh ru b s to h i g h
temperatu res
• T h e saf est an d pref erred ven ti n g meth od i s to ext en d
th e ven t verti cally th rou g h th e roof or ab ove th e roof
*Recommended to prevent condensation on windows and thermal breakage. **This is a recommended distance. For additional requirements check local codes.
