System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin
66
Ambient Operating
Conditions
Temperature: -40 to 66C (-40 to 150F) when using 0–10 VDC outputs;
-40 to 40C (-40 to 104F) when using 4–20 mA outputs
Humidity: Up to 95% RH non-condensing; Maximum Dew Point 29C (85F)
Ambient Shipping and
Storage Conditions
Temperature: -40 to 80C (-40 to 176F)
Humidity: Up to 95% RH non-condensing; Maximum Dew Point 29C (85F)
Analog Output Voltage Mode (0–10 VDC):
10 VDC maximum output voltage
10 mA maximum output current
Requires an external load of 1,000 ohms or more
The AO operates in Voltage Mode when connected to devices with impedance greater than
1,000 ohms. Devices that fall below 1,000 ohms may not operate as intended with Voltage
Mode applications.
Current Mode (4–20 mA):
Requires an external load between 0–300 ohms
The AO operates in Current Mode when connected to devices with impedance less than
300 ohms. Devices that rise above 300 ohms may not operate as intended with Current Mode
applications.
Enclosure Type 1, IP20 High-Impact Thermoplastic
Dimensions (H x W x D) 127 x 61 x 61 mm (5.00 x 2.38 x 2.38 in.)
Weight C450SPN-1C: 150 g (0.33 lb)
C450SQN-1C: 150 g (0.33 lb)
Compliance United States: UL 60730-1, File E27734; FCC Compliant to CFR47, Part 15, Subpart B,
Class B
Canada: cULus Listed; CAN/CSA-E60730-1, File E27734; Industry Canada (IC) Compliant to
Canadian ICES-003, Class B limits
Europe: CE Mark – Johnson Controls declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
Australia and New Zealand: RCM mark, Australia/NZ emissions compliant
C450SBN-3C and C450SCN-3C Expansion Modules with Relay Output
Product C450SBN-3C: System 450 Expansion Module with one SPDT output relay
C450SCN-3C: System 450 Expansion Module with two SPDT output relays
Power Consumption C450SBN-3C: 0.8 VA maximum
C450SCN-3C: 1.2 VA maximum
Supply Power Internal Supply Power: C450YNN-1C Power Supply Module
External Supply Power: 24 VAC (20–30 VAC) Safety Extra-Low Voltage (SELV) (Europe),
Class 2 (North America), 50/60 Hz, 10 VA minimum
Note: A System 450 control module or module assembly can use an internal or an external
supply power source, but must not be connected to both simultaneously.
Ambient Operating
Conditions
Temperature: -40 to 66C (-40 to 150F)
Humidity: Up to 95% RH non-condensing; Maximum Dew Point 29C (85F)
Ambient Shipping and
Storage Conditions
Temperature: -40 to 80C (-40 to 176F)
Humidity: Up to 95% RH non-condensing; Maximum Dew Point 29C (85F)
Output Relay Contacts General: 1/2 HP at 120/240 VAC, SPDT
Specific: AC Motor Ratings 120 VAC 208/240 VAC
AC Full-Load Amperes: 9.8 A 4.9 A
AC Locked-Rotor Amperes: 58.8 A 29.4 A
_____________________________________
10 Amperes AC Non-inductive at 24/240 VAC
Pilot Duty: 125 VA at 24/240 VAC
C450SPN-1C and C450SQN-1C Expansion Modules with Analog Output
