ACID DISPENSER Installation and User’s Guide
2
Liquid Crystal Display (LCD): The system LCD displays backlighting for easy
viewing of the menu items and status messages. Each button press will light the
display. When an event message is displayed, the backlight also lights.
System Status LED indication: Shows green when the system is running normally
and red if an error occurred. See page 6 for error conditions.
Menu/Button: Access and exit from the menu. While in a menu or sub-menu, use
this button to go back to a previous menu level or item. If no menu activity is detected
after 30 seconds, the main screen is displayed. All menu settings are permanently
saved and retained in the control panel even after the IntellipH
®
Controller is powered
off.
Less / More buttons: Scroll through the main menu items and adjust or change
settings. Use these buttons after pressing the Menu button to scroll through the main
menu items.
Enter button: Select a menu choice or save changes. While system is in normal
mode, press this button to show the system settings. The display will automatically
revert back to the normal display mode after 30 seconds from the last selection.
IntellipH
®
Controller Control Panel
1
3
4
5
2
1
2
3
4
5
ylkeewHpkcehC .
T otnottubEROMsserp,Hplooprewolo
TNUOMAESNEPSIDesaercni .
T otnottubSSELsserp,Hploopesiaro
TNUOMAESNEPSIDesaerced .
UNEM
AREPO TION
esU ro .snoitceleshguorhtllorcsotnottub
.eciohctcelesotRETNEsserP
.snoitcelesyalpsidotUNEMsserP
