ACID DISPENSER Installation and User’s Guide INTELLIPH
®
ACID DISPENSER Installation and User’s Guide
History Data
The History Data feature allows you to collect and view the operating history of the
IntellipH unit. To access the IntellipH (SCG) history data, press ENTER. The following list
is displayed:
XXXX DOSES: The number of hourly doses successfully dispensed since installation.
Every automatic dispense increments this counter. This feature is useful to verify the unit is
dispensing acid.
XXXX DIDN’T DOSE: The number of doses not dispensed due to the following conditions:
• Low Water Temp. (< 52° F)
• No Flow
• No Communications
• Low Salt
• Clean Cell
Superchlor Mode
This mode sets the IntelliChlor
®
SCG output to 100% for 24 hours of pump time.
Note: “Superchlor” mode is equivalent to “Boost” mode in stand-alone operation for
IntelliChlor
®
SCG. In “Superchlor” mode, the pool filter pump is not controlled by the
IntellipH
®
Controller.
Set Cell Output
This setting controls IntelliChlor SCG sanitizer output and has a range of 0% -100%. The
default factory setting is 60%. Increasing or decreasing the cell output percentage will
increase or decrease chlorine production in your pool.
This feature replaces the MORE and LESS button on the IntelliChlor SCG. When the
IntelliChlor SCG is connected to IntellipH controller, the “More” and “Less” buttons on the
IntelliChlor SCG are disabled.
Cell Output LED’s IntelliChlor SCG
Displayed “Sanitizer Output” LED Display
0 0 All LEDs are Off
1 - 29 20%
30 - 49 20% 40%
50 - 69 20%, 40% 60%
70 - 89 20%, 40%, 60% 80%
90 - 100 20%, 40%, 60%, 80% 100% (All LEDs are On)
Cell Status
This menu allows you to view the current salinity and temperature of your pool as provided
from the IntelliChlor cell.
SALT : Displays the salinity in ppm.
TEMP: Displays the water temperature in °F.
SALT: 4000 PPM
TEMP: 75 F
XXXX DOSES
XXXX DIDN’T DOSE
5
