Pentax G7H+ - The Bottom of Receiver

8
2.2.3.The bottom of Receiver
Figure 2-6 G7H+ bottom
Figure 2- 3 5-PIN interface Figure 2- 4 7-PIN interface
❶ 5PIN LEMO Connect to external radio and external battery
❷ Radio antenna connector Connect to radio antenna
❸ 7PIN LEMO Connect to PC or handheld, USB + serial port
