When shooting with the viewfinder, the following information
appears in the viewfinder.
t Memo
• You can adjust the diopter in the
viewfinder using the diopter
adjustment lever. If it is difficult to
adjust the diopter adjustment lever,
lift up and remove the eyecup.
Adjust the lever until the AF frame
in the viewfinder looks sharp and
clear.
Viewfinder
1 AF frame 12 AE Lock
2 Spot metering frame 13 Change AF Point
3 AF point 14 AE Metering
4 Flash indicator 15
Shake Reduction
5 Focus Method 16 Flash Exposure
Compensation
6 Shutter speed
7 Aperture value 17 EV Compensation/
Exposure Bracketing
8 Focus indicator
9 EV bar scale 18 File Format
10 ISO/ISO AUTO
11 Sensitivity/Exposure
compensation value
1
4
18
1716151413
61011
12
2
1
3
5 7 8 9
