Names and Functions of Working
Parts
* In the illustrations above, the back and bottom sides of the camera are shown
with the Eyecup F
P removed.
Camera
Tripod socket
Battery cover
Self-Timer lamp/
Remote control receiver
AF coupler
Mirror
Lens unlock button
Lens information
contacts
Card cover
Battery cover
unlock lever
Battery grip connector
terminal
Strap lug
Hot shoe
Lens mount index
(red dot)
Card access
lamp
Built-in Flash
USB/Video terminal
DC input terminal
LCD panel
Terminal cover
Cable switch terminal
Viewfinder
Diopter adjustment lever
Monitor
