EN-18
Using the AC Adapter with a Household Power Supply
(Optional Accessory)
Use of the AC adapter kit K-AC51 (optional) with a household power supply is recommended if you intend to
use the camera for a long time or connect it to a computer.
(The AC adapter kit K-AC51 includes AC adapter D-AC5, DC coupler D-DC51, and AC plug cord D-CO2.)
1. Connect the DC terminal of the AC adapter to the DC input terminal of the DC coupler.
2. Make sure that the camera is turned off and open the battery/card cover.
Pull the battery/card cover in the direction of c and flip the cover open in the direction of d.
3. Insert the DC coupler into the battery compartment, making sure the (+) and (–) on the coupler match the
(+) and (–) on the battery compartment.
To power outlet
4
AC adapter
AC plug cord
DC terminal
2
3
1
5
6
DC input terminal
DC coupler
DC coupler cable cover
DC coupler cable
To Next Page
