USER MANUAL
Peplink Balance Series
6.9 Peplink Balance 1350
6.9.1 Front Panel Appearance
Status indicated in the Front Panel is as follows:
LAN Port, WAN 1 – 13 Ports
Right LED
ORANGE – 1000 Mbps
GREEN– 100 Mbps
OFF – 10 Mbps
Left LED
Solid – Port is connected without traffic
Blinking – Data is transferring
OFF – Port is not connected
Port Type
Auto MDI/MDI-X ports
LED Indicator
Power LED
OFF – Power off
GREEN– Power on
Console & USB Ports
Console Port
Reserved for engineering use
USB Ports
For connecting a 4G/3G USB modem.
Console Port
LCD Controls
LAN Port
WAN Ports
Power LED
LCD Display
USB Ports
http://www.peplink.com -35 / 207 - Copyright © 2013 Peplink

peplink 310 Specifications

General

Load Balancing	Yes
VPN Support	Yes
Power over Ethernet (PoE)	No
LAN Ports	4
Power Input	12V DC
Cellular Connectivity	Optional
Operating Temperature	0°C to 40°C
