HART Multiplexer System KFD*-HM*-16
System Description
2018-04
13
3.4.1 External Mounting
The multiplexer master and multiplexer slaves are connected to a termination board.
The termination board forwards the signals via screw terminals. The termination board
establishes the connection to the connected multiplexer masters and multiplexer slaves in
parallel or series. This type of mounting is independent of the process control system used and
of any existing control units.
Figure 3.3
Converter
26 -pin ribbon cable
14-pin ribbon cable
DIN mounting rail
up to 31 HART multiplexer masters
up to 15 HART multiplexer slaves per master
24 V DC
RS-485
connection
Up to 16
field devices
Up to 16
field devices
DCS
Computer-based
maintenance station
1
2
3
4
5
6
7
8
19
1713 1816
20
14
21
15
KFD0-HMM-16
KFD0-HMS-16
1
3
4
6
2
5
13 15
12
9
10
7
14
11
8
KFD2-EB2
ERR PWR
!
5 AT
IIIS1
Termination
board
Termination
board
Power Rail
