HART Multiplexer System KFD*-HM*-16
Configuration
2018-04
43
The multiplexer devices must be added to the project manually.
Inserting Multiplexer Devices via Device Catalog
1. Open the device catalog by clicking View > Device catalog
2. Use drag-and-drop to move the KFD2-HMM-16 DTM from the device catalog to
the HART communication DTM (e. g. COM8) in the project tree.
The KFD2-HMM-16 DTM is added to the project.
Inserting Multiplexer Devices via Context Menu
1. In the project window, right-click to select the HART communication DTM (e. g. COM8).
2. In the context menu, select Add device.
3. Select the KFD2-HMM-16 DTM from the list and confirm by clicking OK.
The KFD2-HMM-16 DTM is added to the project.
Note!
To establish the connection to a device in the project tree or to disconnect the connection,
right-click to select the corresponding device in the project window. In the context menu,
select Connect or Disconnect.
Alternatively, you can select the device in the project window and click the corresponding field
in the command bar.
