4.15 Surf SOHO
4.15.1 Panel Appearance
4.15.2 LED Indicators
T
he statuses indicated by the front panel LEDs are as follows:
Wi-Fi and Status Indicators
Wi-Fi
OFF Disabled Intermittent
Blinking Enabled but no client connected
ON Client(s) connected to wireless network
Continuous
blinking
Transferring data to wireless network
Status
OFF System initializing
Red Booting up or busy
Green Ready state
LAN and Ethernet WAN Ports
Green LED ON 100/1000 Mbps
Orange LED
Blinking Data is transferring
OFF
No data is being transferred or port is not
connected
Port type Auto MDI/MDI-X ports
Wi-Fi Signal
Off No connection
Signal strength Wi-Fi signal strength (low, medium, and high)
