Pepwave MAX and Surf User Manual
http://www.pepwave.com 38 Copyright @ 2016 Pepwave
6.2 Constructing the Network
At a high level, construct the network according to the following steps:
1. With an Ethernet cable, connect a computer to one of the LAN ports on the
Pepwave router. Repeat with different cables for up to 4 computers to be
connected.
2. With another Ethernet cable or a USB modem/Wi-Fi ant
enna/PC
Card/Express Card, connect to one of the WAN ports on the Pepwave
router. Repeat the same procedure for other WAN ports.
3. Connect the power adapter to the power connector on the rear panel of the
Pepwave router, and then plug it into a power outlet.
The following figure schematically illustrates the resulting configuration:
