Perfect Flame 720-0335 - Cart Frame Assembly

11
CART FRAME ASSEMBLY
Assembly the cart frame with 4 pcs 1/4” X 10mm truss head screws and 4 pcs of 1/4’’split
locks (Pack C) to the side panels and use 1 pc 5/32” X 10mm truss head screw and 1 pc of
5/32” split lock (Pack B) to cart clapboard as shown figure.
Pack C
Pack B
