18
SIDE BURNER FLEX GAS LINE ASSEMBLY
BATTERY INSTALLATION
Caution: After you finished last
step you need to connect the
side burner igniter line with the
side burner gas valve or you
can’t ignite side burner.
1. Remove the ignition button housing.
2. Insert the battery into the housing with
the positive terminal facing outward.
3. Replace the ignition button housing
after the battery has been installed.
Insert the side burner flex gas line with side
burner orifice through the hole of the side
burner base and then push the nut until it
forward to lock the side burner orifice.
To Next Page
