Perfect Flame 720-0335 - Parts List

REF QTY REF QTY
PARTS LIST
Model No. 720-0335
#
DESCRIPTION
#
DESCRIPTION
01 Temperature Gauge 2 35 Side Panel, Left 1
02 Side Lid 1 36 Front Trim Panel, Left 1
03 Main Lid ” X 1 3/4” 1 37 Swivel Caster 3 2
04 Logo 1 38 Bottom Panel 1
05 Main Lid Heat Insulating Spacer 4 39 Cart Clapboard 1
06 Main Lid Handle Heat Insulating
Spacer Seat
rim Piece, Bottom Panel 4 40 Front T 1
07 Main Lid Handle Seat 4 41 Wheel 2
08 Main Lid Handle Tube 1 42 Lighting Rod 1
09 Side Lid Handle Tube 1 43 Door 1
10 Rotisserie Orifice Brass Elbow 1 44 Drawer Slide, Right 2
11 Rotisserie Burner Flex Gas Line 1 45 Drawer Heat Shield 1
12 Side Shelf Trim Panel, Left 1 46 Drawer Slide Bracket, Left 2
13 Main Burner Bowl Assembly lide, Left 1 47 Drawer S 2
14 Side Shelf, Left 1 48 Drawer 2
15 Side Shelf Front Panel, Left 1 49 Cart Frame 1
16 Gas Valve Nip 5 50 Door Magnet 1
17 Front Baffle 1 51 Hinge Bracket, Top (Right) 1
18 Main Burner Gas Valve 3 52 Warming Rack 1
19 Main Manifold 1 53 Cooking Grid 2
20 Main Control Panel 1 54 Flame Tamer 3
21 Bezel 6 55 Main Burner 3
22 Control Knob 6 56 Main Igniter Wire 3
23 Utility Drawer Slide, Right 1 57 Rear Baffle 1
24 Utility Drawer 1 58 Rotisserie Burner 1
25 Utility Drawer Handle 4 59 Rotisserie Burner Gas Collector 1
26 Grease Pan 2 60 Rotisserie Burner Cooking Grid 1
27 Fire Box Heat Shield 1 61 Rotisserie Back Panel 1
28 Rotisserie Gas Valve 1 62 Searing Burner Flex Gas Line 1
29 Thermocouple Gas Valve rate 1 63 Side Cooking G 1
30 Electronic Igniter Box 1 64 Thermocouple 1
31 Side Burner Gas Hose 1 65 Searing Side Burner 1
32 Wire Cover 2 66 Searing Burner Orifice 1
33 Warming Drawer Slide, Right 1 67 Sear Burner Igniter Wire 1
34 Left Pie Cart Corner Frame, Top Assembly 1 68 Sear Burner Bowl 1
