TO LOCK SAW:
• Press the switch down.
• Remove the switch key from the switch and store in a safe,
secure location.
WARNING: Always remove the switch key when the tool
is not in use and keep it in a safe place. In the event of a power
failure, turn the switch OFF ( O ) and remove the key. This
action will prevent the tool from accidentally starting when
power returns.
WARNING: ALWAYS make sure your workpiece is not in
contact with the blade before operating the switch to start the
tool. Failure to heed this warning may cause the workpiece to
be kicked back toward the operator and result in serious
personal injury
WARNING: To reduce the risk of accidental starting,
always make sure the switch is in the OFF ( O ) position
before plugging tool into the power source.
SPECIFICATIONS
Rating: 120 V, 60 Hz
Motor: 15A
No load speed: 4500 RPM
Saw blade: 10" (25.4cm), 40-tooth carbide-tipped
Arbor size: 5/8" (15.9 mm)
Bevel range: 0°- 45°
Main table size: 24" x 21-1/16" (610x535mm)
Extension table size: 6" x21-1/16" (150x535mm)
Outfeed support size: 24" x2-1/2" (610x65mm)
Cutting Depth at 0 °: 3 1/2" (89mm)
Cutting Depth at 45°: 2 5/32" (55mm)
Max. cut right of blade with rip fence: 30" (762mm)
Net weight with leg stand: 87 lbs (39.5kg)
OVERVIEW / SPECIFICATIONS
Figure 3
_ 12 _
