48 . High-Performance Lambda Spectrometers Hardware Guide
Removing the Sample Compartment Windows
 Each window has a magnetic frame and can be removed carefully by hand.
Replace the window in its original position.
Removing the Sample Compartment Baseplate
1. With the sample compartment cover open or removed, undo the four thumbscrews
shown in Figure 16.
Figure 16 Four thumbscrews on the sample compartment baseplate
2. Lift the baseplate up and off the locating pins, and remove it from the sample
compartment.
Thumbscrews
Thumbscrews
