Perkins 1104 - Fuel System Secondary Filter;Water Separator - Drain

Illustration 54 g03721682
Typical examples
1. Place a suitable container below the water
separator.
2. Open the drain (1). Allow the fluid to drain into the
container.
3. When clean fuel drains from the water separator
close the drain (1). Tighten the drain by hand
pressure only. Dispose of the drained fluid
correctly.
i06020909
Fuel System Secondary Filter/
Water Separator - Drain
Illustration 55 g03776762
Typical example
The secondary fuel filter that is shown in illustration
55 has also been designed as a water separator.
1. Place a suitable container below the filter.
76 SEBU7833
Refill Capacities
Fuel System Secondary Filter/Water Separator - Drain
